Fiber laser cutting technology has transformed modern manufacturing by delivering high-speed, precision cutting for various metals. At Nova Laser, we specialize in supplying premium Fiber Laser Cutting Heads from leading brands:
✅ Raytools – Models: BM110, BM111, BM06K
✅ WSX – Models: NC30, NC63
These cutting heads are designed for optimal performance, high precision, and durability, making them ideal for industries like automotive, aerospace, sheet metal fabrication, and industrial manufacturing.
This guide provides technical specifications, material compatibility, cutting thickness capacities, and key features to help you select the right cutting head for your fiber laser machine.
1. What is a Fiber Laser Cutting Head?
A Fiber Laser Cutting Head is the most crucial component of a fiber laser cutting machine. It plays a key role in:
- 🔹 Focusing the laser beam for precision cutting
- 🔹 Controlling gas flow (oxygen, nitrogen, or air) to optimize the cutting process
- 🔹 Adjusting focal length for different material thicknesses
- 🔹 Protecting internal optics from contamination and overheating
2. Raytools Fiber Laser Cutting Heads
Raytools is a globally trusted brand known for its advanced laser cutting technology, high durability, precision, and efficient gas flow management.
Raytools BM110 – Entry-Level, Auto-Focus Cutting Head
✅ Laser Power Support: 500W – 3kW
✅ Drive and Motor: Lead Shine
✅ Auto-Focus: Yes
✅ Material Compatibility: Stainless Steel, Mild Steel, Aluminum, Copper
✅ Max Cutting Thickness:
- Mild Steel: Up to 12-16mm
- Stainless Steel: Up to 5-8mm
- Aluminum & Copper: Up to 3mm
- Copper: Up to 0.8mm
✅ Key Features:
- Ideal for low to mid-power laser machines
- Economical and easy to maintain
Raytools BM111 – High-Speed, Auto-Focus Cutting Head
✅ Laser Power Support: 1kW – 3kW
✅ Drive and Motor: Yaskawa & AhedTech
✅ Auto-Focus: Yes (Motorized)
✅ Material Compatibility: Stainless Steel, Carbon Steel, Brass, Aluminum
✅ Max Cutting Thickness:
- Mild Steel: Up to 20mm
- Stainless Steel: Up to 10mm
- Aluminum & Copper: Up to 6mm
✅ Key Features:
- High-speed cutting with auto-focus adjustment
- Collision Protection Sensor to prevent damage
- Water-Cooling System for a longer lifespan
Raytools BM06K – Heavy-Duty, High-Power Cutting Head
✅ Laser Power Support: 3kW – 6kW
✅ Drive and Motor: Lead Shine
✅ Auto-Focus: Yes (Advanced Auto-Focus)
✅ Material Compatibility: Stainless Steel, Mild Steel, Aluminum, Brass, Copper, Titanium
✅ Max Cutting Thickness:
- Mild Steel: Up to 25mm
- Stainless Steel: Up to 14mm
- Aluminum: Up to 8mm
- Copper: Up to 3mm
✅ Key Features:
- Optimized gas flow system for precision cutting
- Durable ceramic nozzle mount for extended lifespan
- Designed for high-power fiber laser systems
3. WSX Fiber Laser Cutting Heads
WSX laser cutting heads are recognized for their robust design, high-speed auto-focus, and superior dust protection, making them ideal for industrial applications.
WSX NC30 – Mid-Range Auto-Focus Cutting Head
✅ Laser Power Support: 1kW – 6kW
✅ Drive and Motor: Lead Shine
✅ Auto-Focus: Yes
✅ Material Compatibility: Stainless Steel, Mild Steel, Aluminum, Copper
✅ Max Cutting Thickness:
- Mild Steel: Up to 12-16mm
- Stainless Steel: Up to 5-8mm
- Aluminum & Copper: Up to 3mm
- Copper: Up to 0.8mm
✅ Key Features:
- High-speed motorized auto-focus
- Anti-collision protection for safety
- Dust-proof design for extended lifespan
WSX NC63 – Ultra High-Power Cutting Head
✅ Laser Power Support: 3kW – 6kW
✅ Drive and Motor: Lead Shine
✅ Auto-Focus: Yes (Advanced Auto-Focus)
✅ Material Compatibility: Stainless Steel, Mild Steel, Aluminum, Brass, Copper, Titanium
✅ Max Cutting Thickness:
- Mild Steel: Up to 25mm
- Stainless Steel: Up to 14mm
- Aluminum: Up to 8mm
- Copper: Up to 3mm
✅ Key Features:
- Efficient water cooling system for stability
- Enhanced beam collimation for superior edge quality
-
Designed for ultra-thick metal cutting applications
4. Raytools vs. WSX – Which Cutting Head is Right for You?
Selecting the right cutting head depends on your laser machine’s power, the materials you work with, and your cutting requirements. Here’s a quick comparison:
5. Why Choose Nova Laser?
✅ Genuine Products – Directly sourced from Raytools & WSX
✅ Best Prices – No middlemen, competitive pricing
✅ Ready Stock – Fast delivery across India
✅ Expert Guidance – Helping you choose the best cutting head
✅ Local Warranty & Support – Hassle-free service and replacements
